Deep Groove Ball Bearings
RLS30 Deep Groove Ball Bearing
95.25 × 171.45 × 28.575 mm
RLS30 is a deep groove ball bearing from the RLS series with a 95.25 mm bore, a 171.45 mm outside diameter and a 28.575 mm width. It has a dynamic load rating of 87,083 N and a static load rating of 65,508 N, weighing about 2.5 kg. The radial cross-section (D − d) is 76.2 mm.
Brands: NTN, FAG, SKF, NBC, DTC, SLS
RLS30 Specifications
| Bearing No. | RLS30 |
|---|---|
| d (Bore) | 95.25 mm |
| D (Outer Dia.) | 171.45 mm |
| B (Width) | 28.575 mm |
| Dynamic Load | 87,083 N |
| Static Load | 65,508 N |
| Weight | 2.5 kg |
| Series | RLS Series Single Row Deep Groove Ball Bearings |
RLS30 Variants & Designations
Typical designations for this size, subject to availability. Full suffix meanings are listed on the RLS series page.
Other Bearings with 95.25 mm Bore
| Bearing No. | Series | D (Outer Dia.) mm | Dynamic Load N |
|---|---|---|---|
| RMS30 | RMS | 209.55 | 122,386 |
RLS30 — Frequently Asked Questions
What are the dimensions of the RLS30 bearing?
The RLS30 has a bore (d) of 95.25 mm, an outside diameter (D) of 171.45 mm and a width of 28.575 mm, so it is written 95.25 × 171.45 × 28.575 mm.
What is the load rating of the RLS30?
Dynamic load rating 87,083 N and static load rating 65,508 N.
Is the RLS30 available with seals, special clearance or other options?
Yes, subject to availability. Typical designations include RLS30-ZZ (metal shields on both sides), RLS30-2RS (rubber seals on both sides), RLS30 C3 (radial clearance larger than normal), RLS30-2RS C3 (sealed, with C3 clearance). Tell us the exact designation you need in a quote request.
Which other bearings have the same 95.25 mm bore as the RLS30?
Other deep groove ball bearings with a 95.25 mm bore include RMS30 (209.55 mm OD). A larger outside diameter generally means a higher load rating.
Do you supply the RLS30 bearing across India?
Yes. Logass Trade Centre supplies the RLS30 Pan India with technical support, from single pieces to bulk orders. Use the quote button to share your quantity and brand preference.
Can’t find your size?
We supply sizes, brands and special versions of deep groove ball bearings that are not listed on this page. Type the exact size or designation you need and send it to us for a quote.
Need pricing on the RLS30?
Share your quantity and preferred brand — our technical team will confirm availability and pricing within one business day.
