Deep Groove Ball Bearings
62207 Deep Groove Ball Bearing
35 × 72 × 23 mm
62207 is a deep groove ball bearing from the 62200 series with a 35 mm bore, a 72 mm outside diameter and a 23 mm width. It has a dynamic load rating of 25,700 N and a static load rating of 15,300 N and a speed rating of 11,000 rpm (oil lubrication), weighing about 0.31 kg. The radial cross-section (D − d) is 37 mm.
Brands: NTN, FAG, SKF, NBC, DTC, SLS
62207 Specifications
| Bearing No. | 62207 |
|---|---|
| d (Bore) | 35 mm |
| D (Outer Dia.) | 72 mm |
| B (Width) | 23 mm |
| Dynamic Load | 25,700 N |
| Static Load | 15,300 N |
| Max. RPM | 11,000 |
| Weight | 0.31 kg |
| Series | 62200 Series Single Row Deep Groove Ball Bearings |
62207 Variants & Designations
Typical designations for this size, subject to availability. Full suffix meanings are listed on the 62200 series page.
Neighbouring Sizes in the 62200 Series
62207 — Frequently Asked Questions
What are the dimensions of the 62207 bearing?
The 62207 has a bore (d) of 35 mm, an outside diameter (D) of 72 mm and a width of 23 mm, so it is written 35 × 72 × 23 mm.
What is the load rating of the 62207?
Dynamic load rating 25,700 N and static load rating 15,300 N. The speed rating is 11,000 rpm with oil lubrication; for grease lubrication use about 75% of that value.
Is the 62207 available with seals, special clearance or other options?
Yes, subject to availability. Typical designations include 62207-ZZ (metal shields on both sides), 62207-2RS (rubber seals on both sides), 62207 C3 (radial clearance larger than normal), 62207-2RS C3 (sealed, with C3 clearance). Tell us the exact designation you need in a quote request.
Which other bearings have the same 35 mm bore as the 62207?
Other deep groove ball bearings with a 35 mm bore include 6807 (47 mm OD), 6907 (55 mm OD), 6007 (62 mm OD), 16007 (62 mm OD). A larger outside diameter generally means a higher load rating.
Do you supply the 62207 bearing across India?
Yes. Logass Trade Centre supplies the 62207 Pan India with technical support, from single pieces to bulk orders. Use the quote button to share your quantity and brand preference.
