Thrust Ball Bearings
52414 Thrust Ball Bearing
55 × 150 × 107 mm
52414 is a thrust ball bearing from the 524 series with a 55 mm bore, a 150 mm outside diameter and a 107 mm height. It has a dynamic load rating of 225,000 N and a static load rating of 499,500 N and a speed rating of 1,350 rpm (oil lubrication), weighing about 9.71 kg. The radial cross-section (D − d) is 95 mm.
Brands: NTN, FAG, SKF, NBC, DTC, SLS
52414 Specifications
| Bearing No. | 52414 |
|---|---|
| d (Bore) | 55 mm |
| D (Outer Dia.) | 150 mm |
| H (Height) | 107 mm |
| Dynamic Load | 225,000 N |
| Static Load | 499,500 N |
| Max. RPM | 1,350 |
| Weight | 9.71 kg |
| Series | 524 Series Double Direction Thrust Ball Bearings |
52414 Variants & Designations
Typical designations for this size, subject to availability. Full suffix meanings are listed on the 524 series page.
Neighbouring Sizes in the 524 Series
52414 — Frequently Asked Questions
What are the dimensions of the 52414 bearing?
The 52414 has a bore (d) of 55 mm, an outside diameter (D) of 150 mm and a height of 107 mm, so it is written 55 × 150 × 107 mm.
What is the load rating of the 52414?
Dynamic load rating 225,000 N and static load rating 499,500 N. The speed rating is 1,350 rpm with oil lubrication; for grease lubrication use about 75% of that value.
Is the 52414 available with seals, special clearance or other options?
Yes, subject to availability. Typical designations include 52414 M (machined brass cage). Tell us the exact designation you need in a quote request.
Which other bearings have the same 55 mm bore as the 52414?
Other thrust ball bearings with a 55 mm bore include 51111 (78 mm OD), 51211 (90 mm OD), 53211 (90 mm OD), 52213 (100 mm OD). A larger outside diameter generally means a higher load rating.
Do you supply the 52414 bearing across India?
Yes. Logass Trade Centre supplies the 52414 Pan India with technical support, from single pieces to bulk orders. Use the quote button to share your quantity and brand preference.
