Deep Groove Ball Bearings
4210 Deep Groove Ball Bearing
50 × 90 × 23 mm
4210 is a deep groove ball bearing from the 4200 series with a 50 mm bore, a 90 mm outside diameter and a 23 mm width. It has a dynamic load rating of 36,900 N and a static load rating of 36,000 N and a speed rating of 5,400 rpm (oil lubrication), weighing about 0.58 kg. The radial cross-section (D − d) is 40 mm.
Brands: NTN, FAG, SKF, NBC, DTC, SLS
4210 Specifications
| Bearing No. | 4210 |
|---|---|
| d (Bore) | 50 mm |
| D (Outer Dia.) | 90 mm |
| B (Width) | 23 mm |
| Dynamic Load | 36,900 N |
| Static Load | 36,000 N |
| Max. RPM | 5,400 |
| Weight | 0.58 kg |
| Series | 4200 Series Double Row Deep Groove Ball Bearings |
4210 Variants & Designations
Typical designations for this size, subject to availability. Full suffix meanings are listed on the 4200 series page.
Neighbouring Sizes in the 4200 Series
4210 — Frequently Asked Questions
What are the dimensions of the 4210 bearing?
The 4210 has a bore (d) of 50 mm, an outside diameter (D) of 90 mm and a width of 23 mm, so it is written 50 × 90 × 23 mm.
What is the load rating of the 4210?
Dynamic load rating 36,900 N and static load rating 36,000 N. The speed rating is 5,400 rpm with oil lubrication; for grease lubrication use about 75% of that value.
Is the 4210 available with seals, special clearance or other options?
Yes, subject to availability. Typical designations include 4210-ZZ (metal shields on both sides), 4210-2RS (rubber seals on both sides), 4210 C3 (radial clearance larger than normal), 4210-2RS C3 (sealed, with C3 clearance). Tell us the exact designation you need in a quote request.
Which other bearings have the same 50 mm bore as the 4210?
Other deep groove ball bearings with a 50 mm bore include 6810 (65 mm OD), 6910 (72 mm OD), 6010 (80 mm OD), 16010 (80 mm OD). A larger outside diameter generally means a higher load rating.
Do you supply the 4210 bearing across India?
Yes. Logass Trade Centre supplies the 4210 Pan India with technical support, from single pieces to bulk orders. Use the quote button to share your quantity and brand preference.
Can’t find your size?
We supply sizes, brands and special versions of deep groove ball bearings that are not listed on this page. Type the exact size or designation you need and send it to us for a quote.
Need pricing on the 4210?
Share your quantity and preferred brand — our technical team will confirm availability and pricing within one business day.
